Butterfly Valves

500 INR/Piece

Get a Price/Quote

Product Details:

Supply Ability : 1000 , , Piece Per Day
Click to view more
Share Your Product:

Request To Call Back Send Inquiry

Price And Quantity

Minimum Order Quantity 10 , , Piece
Price 500 INR/Piece

Trade Information

Supply Ability 1000 , , Piece Per Day
Delivery Time 1 Week

Product Description

For our esteemed customers, we are offering finest and most quality high collections of Butterfly Valves. These valves are acquired from best vendors of the market. These valves are easy to install. These valves are available in many grades.

PRODUCT DESCRIPTION :

Product : 'SANT' Cast Iron Butterfly Valve
Product Standard : Lever Operated / Gear & Handwheel Operated
Pressure / Class / Rating : PN 1.6
Body Material cum Standard : Cast Iron IS:210 Gr.FG200
Description : Wafer Type
Type of Seat : Nitrile Rubber Lining
Type of Disc : SG Iron
Trim : SS AISI410
End Details : Suitable insertion between Flanges as per BS 10 Table D/E ANSI B 16.1 CI-125

TESTING & CERTIFICATION :

Body Test Pressure : 2.4MPa (348 Psig) Hyd
Seat Test Pressure : 1.6MPa (232 Psig) Hyd
Note : Gear system will be provided for size above 150mm.
Our Works' Test Certificate is furnished with every supply.

MATERIALS

Components	Materials	Specifications
Body	Cast Iron	IS:210 Gr.FG200
Disc	S.G. Iron	IS:1865 Gr.SG400/12
Shaft	Stainless Steel	AISI410
Seat	Elastomers (Nitrile)	--
Gear	MS	--
Lever / Handwheel	Cast Iron / Carbon Steel	IS:210 Gr.FG200 / IS:2004:1991

DIMENSIONS IN mm

Nominal Size	Nominal Size (Inches)	F	C	D	LL	H	W
40	1.1/2	33	61	82	200	145	--
50	2	43	65	95	200	150	--
65	2.1/2	46	77	106	200	160	--
80	3	46	85	124	200	170	--
100	4	52	102	152	260	195	--
125	5	56	112	173	260	210	--
150	6	56	132	209	260	235	--
200	8	60	170	260	--	335	225
250	10	68	210	315	--	375	225
300	12	78	240	370	--	400	225
