Gate Valves

Gate Valves

Product Details:

X

Product Description

We are one of the leading manufacturers and suppliers of supreme quality range of Zoloto Gate ValvesThese are manufactured at par with industry standards by utilizing supreme grade materials. The offered valves have applications in plumbing system for regulating the pressure of fluids. Moreover, our valued clients can avail these premium quality Zoloto Gate Valves from us at market leading prices.

Features:

  • Sturdy design
  • Long service life
  • Seamless finish


Salient Features :

  • Flanged Ends to BS 10 Table 'F'.
  • Screwed on Bonnet, Rising Stem.
  • Provision for re-packing under pressure.
  • Renewable 13% Cr. Stainless Steel (S.S 410) working parts.
  • Handwheel Operated.

Test Pressure (Hydrostatic) :
  • Shell : 35 kg/cm²g (500 psig)
  • Working Pressure (Steam) : 10.55 kg/cm²g (150 psig)
  • Maximum Working Temperature : 225oC



Materials

P.No.

Name of Part

Material of Construction

Specification

Quantity

1

Body

Bronze

IS 318 Gr. LTB 2

1

2

Body Seat Ring

Stainless Steel

ASTM A276 Type 410

1

3

Disc

Stainless Steel

ASTM A276 Type 410

1

4

Disc Nut

Bronze

IS 318 Gr. LTB 2

1

5

Stem

Stainless Steel

ASTM A276 Type 410

1

6

Bonnet

Bronze

IS 318 Gr. LTB 2

1

7

Gland Packing

Asbestos

– – –

8

Gland

Bronze

IS 318 Gr. LTB 2

1

9

Gland Nut

Bronze

IS 318 Gr. LTB 2

1

10

Hand Wheel

Cast Iron

IS 210 Gr. FG 200

1

11

Washer

Carbon Steel

– – –

1

12

Nut

Carbon Steel

– – –

1


Sizes / Dimensions

Size (Inches)

Size (mm)

A +1.5

B ~

ØC ~

1/2

15

82

117

70

3/4

20

96

132

80

1

25

112

148

86

1 1/4

32

119

176

102

1 1/2

40

132

188

115

2

50

157

216

127

2 1/2

65

185

248

170

3

80

213

270

170

4

100

248

332

190
