Fusible Plug

Fusible Plug

Product Details:

X

Product Description

Product Description :



  • Product : 'SANT' Bronze Fusible Plug
  • Type of Pattern : Two piece design
  • Body Material cum Standard : Bronze IBR 282(a)(iv) Gr.B
  • End Details : Screwed male BSP Parallel threads to BS 21.
  • Note : Melting temperature of Fusible Alloy 270°C




Testing & Certification :



  • Hydraulic Test Pressure : 500 Psig. Hyd.
  • Working Pressure : Max. BOP 250 Psig. (17.58Kg/cm²) at 435°F (225°C)
  • Test Certificate in Form III-C as per IBR is furnished with every supply.




Materials :

Components

Materials

Specifications

Body, Cone

Bronze

IBR 282(a)(iv) Gr.B

Fusible Alloy

Lead-Tin Alloy

--


Dimensions In mm :

Nominal Size

Nominal Size (Inches)

F

15

1/2

52

20

3/4

62

25

1

75

32

1.1/4

86

40

1.1/2

90

50

2

97
